Aditya TMT Bars offers a blend of strength and ductility, far in excess of the minimum limits of yield stress in the IS : 1786 standards. The typical values are as high as 450 N/mm2 though the standards specify 415 N /mm2 as normally used by architects. The typical value of ductility as measured by elongation is 18% minimum as against the standard value of 14.5% minimum. Undoubtedly, this ductility guarantees higher levels of safety.

Mechanical Testing
A team of qualified and skilled personnel in combination with state-of-the-art quality testing equipment undertakes complete testing like:

• Impact Testing
• Tensile Testing
• Hardness Testing
• Microstructure Testing
• Elasticity
• Yield Stress

Impact Testing
Premium quality impact testing machines are capable to conduct impact test as per ISI specification

Tensile Testing
Universal Testing Machine is used to test the metals with strength up to 1000 kN. TMT bars can be tested up to 32 mm capacity as per IS 1786 without machining.

Hardness Testing
There a host of Hardness testing equipment duly calibrated by internationally known auditors.

Mechanical Properties

		TMT Fe-415		TMT Fe-500		TMT Fe-500D
Mechanical Properties	Unit	IS1786:2008	Aditya TMT Bars	IS1786:2008	Aditya TMT Bars	IS1786:2008	Aditya TMT Bars
Yield Strength	N/mm2	415 min	450 min	500 min	530 min	500 min	540 min
Tensile Strength	N/mm2	10% more than YS but not less than 485	10% more than YS but not less than 520	8% more than YS but not less than 545	8% more than YS but not less than 600	10% more than YS but not less than 565	10% more than YS but not less than 620
Elongation	%	14.5 min	18 min	12 min	16 min	16 min	18 min

Bendability (Nominal Size mm Mandrai Diameter for different grades IS 1786:2008)

		TMT Fe-415		TMT Fe-500
Operation	Size	IS 1786 : 2008	Aditya TMT Bars	IS 1786:2008	Aditya TMT Bars
Bend	Up to & Incl. 20 mm	3d	<3d	4d	<4d
	Over 20 mm	4d	4d	5d	5d
Re-bend	Up to & Inc. 10 mm	5d	<5d	5d	<5d
	Over 10 mm	7d	7d	7d	7d

WEIGHT TOLERANCE Unit Weight ( Kg/Meter)

	As per IS 1786			Aditya TMT Bars
Size of Bar (mm)	Lower Limit	Upper Limit	Market Average	Range	Average
8	0.367	0.423	0.411	0.367 - 0.398	0.382
10	0.574	0.660	0.641	0.582 – 0.612	0.597
12	0.844	0.932	0.912	0.858 – 0.884	0.871
16	1.501	1.659	1.621	1.514 – 1.581	1.547
20	2.396	2.544	2.511	2.412 – 2.471	2.441
25	3.735	3.966	3.915	3.753 – 3.966	3.859
28	4.685	4.975	4.910	4.715 – 4.827	4.771
32	6.121	6.499	6.511	6.181 – 6.442	6.311
